Better choices.
For real applications.

Supplied by TrueSine

Active Harmonic Filter

AHF / Harmonic current compensation

For electrical networks with non-linear loads such as drives, rectifiers and UPS equipment. An AHF supplies compensating current to address harmonic current distortion; selected configurations can also support reactive current compensation.

Application

Harmonic mitigation

Listed ratings

30 / 60 / 75 / 100 / 150 A; parallel options

System options

3-wire / 4-wire, subject to model

Selection inputs

Load readings, variation & compensation task

Final rating and configuration are confirmed for the application. Listed ratings are based on the supplied product literature.

Supplied by TrueSine

Thyristor Switching Modules

TSM-25 / TSM-50 / TSM-75 / TSM-100

Solid-state capacitor switching for APFC panels, including applications with frequent load changes. Select the module with the capacitor step, controller trigger and protection arrangement in mind.

Power ratings

25 / 50 / 75 / 100 kVAr

Operating voltage

415 V AC

Trigger input

12 / 24 V DC

Frequency range

45–65 Hz

Supplied by TrueSine

IGBT Gate Driver

Isolated gate driving for power conversion

Gate driver selection for industrial converters, inverter bridges and related power electronic applications. Share your IGBT module, supply arrangement and switching requirement to discuss a suitable driver.

Featured brochure model

InstaDrive

Output channels

Dual channel (Top / Bottom)

Peak output current

±10 A (InstaDrive)

Featured protection

Short-circuit protection, soft shutdown & UVLO

The image illustrates the product category. Refer to the InstaDrive brochure for that model's details.

Supplied by TrueSine

Thyristor (Zero Cross) Driver

Micro / Advance

Thyristor driving and control components for suitable panel and power electronics applications. Share the thyristor, control input and circuit requirement for product selection.

View the product brochure and technical datasheet for model information, connections and dimensions.

Confirm model-specific ratings and connection requirements with TrueSine before selection or installation. Full documents are shared through WhatsApp on request.
